Product Description:
A588 Grade A steel plate is made from high strength, low alloy structural steel with a 345Mpa minimum yield point to a thickness of 100mm. This type of steel is perfect for the construction of buildings and other large structures that require extra durability.
If exposed to the elements, A588 Grade A is still suitable for use in its bare condition, making it a popular choice for many applications. The steel can easily withstand even harsh outdoor conditions, ensuring a long-lasting structure.
Additionally, our Gnee steel mill is capable of producing A588 Grade A steel plates in sizes up to 200mm, making it a versatile option for a variety of projects.
Features:
The ASTM A588 steel has a variety of benefits and features that make it a popular choice in various applications. First, it contains a small amount of chromium, copper, and nickel, which allows it to be resistant to atmospheric corrosion. This means that the steel is less likely to rust or deteriorate over time due to exposure to environmental factors.
In addition to its corrosion resistance, the lower weight/strength ratio of ASTM A588 steel makes it an ideal choice for high strength and weather-exposed applications. The lower weight means that it can be used in structures or designs where a heavy weight would cause issues.
Furthermore, the alloy amount in ASTM A588 steel can be ordered for a unique purpose, allowing for customization based on specific needs. This means that the steel can be tailored to the requirements of your project and provide the necessary strength and durability needed.
Another important advantage is that, although initially more expensive than other types of steel, the cost is lower in the long-term due to its corrosion resistance and durability. This makes it a cost-effective choice for many projects in the long run.
Technical Parameters:
Welcome to Gnee Steel
At Gnee Steel, we specialize in supplying ASTM A588 steel plate in A588 Grade A. If you want more information about our A588 Grade A steel plates, please check the following:
ASTM A588 Chemical Composition
| Grade | C | Si | Mn | P | S | Ni | Nb | Cu | Cr | Mo | N | V |
| A588 | 0.19 | 0.30-0.65 | 0.80-1.25 | 0.04 | 0.05 | 0.40 | .. | 0.25-0.40 | 0.40-0.65 | ... | 0.01 | 0.02-0.10 |
The carbon equivalent formula we use is: Ceq = C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15%
Mechanical Properties of A588 Grade A
| Mechanical Property | A588 Grade A Steel Plate |
| Tensile Strength, kis [MPa] | 100mm or under: [485], 100mm-125mm: [460], 125mm-200mm: [435] |
| Yield Strength, min, kis [MPa] | 100mm or under: [345], 100mm-125mm: [315], 125mm-200mm: [290] |
| Elongation in under. [50 mm], min, % | 21 |
| Elongation in under. [50 mm-200mm], min, % | 18 |
Applications:
ASTM A588 steel is a crucial component in constructing some of the most vital structures in the world. It is designed to withstand even the most extreme conditions on earth. When choosing to use ASTM A588 weathering steel instead of standard steel, you can greatly benefit from its corrosion resistance and the unique aesthetic appeal of its patina.
Unlike traditional steel, weathering steel can be used unpainted in both structural and architectural applications. This eliminates painting and maintenance costs, while also reducing overall construction time. By incorporating weathering steel into your building projects, you can ensure that your structures will endure the test of time and harsh weather conditions.
FAQ:
Q: What is the brand name of this Corten Steel Plate?
A: The brand name of this product is GNEE.
Q: What is the model number of this Corten Steel Plate?
A: The model number of this product is ASTM A588.
Q: Where is this Corten Steel Plate manufactured?
A: This product is manufactured in China.
Q: What are the dimensions of this Corten Steel Plate?
A: The dimensions of this product vary depending on the size selected. Please refer to the product specifications for more information.
Q: What is the material composition of this Corten Steel Plate?
A: This product is made of weathering steel, which contains small amounts of copper, chromium, nickel, and phosphorus for added strength and corrosion resistance.
