Astm A335 Cs Seamless Pipe P5 / P9 / P11 / P12 / P22 / P91

Brand Name : Gnee

Model Number : A335

Certification : SGS

Place of Origin : Tianjin

MOQ : 1 Tons

Price : 1,250.00 $

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 Tons per Month

Packaging Details : seaworthy export packing with fumigated wooden pallets or steel pallets

Material : API, ASTM, DIN, GB, API 5CT, API 5L, ASTM A106-2006

Outer Diameter : 25 - 356 mm

Thickness : 4 - 70 mm

Standard : JIS, AiSi, ASTM, GB, DIN, EN

Processing Service : Bending, Welding, Decoiling, Punching, Cutting, Moulding

Type : Round Pipe Tube

Surface : Bare/Oil/Paint/Varnish

Length : 1000-6000mm or Customer's Requirement

Grade : A335

Tolerance : ±1%

Technique : Cold Rolled Hot Rolled

Application : Construcion/Building /Industry

Contact Now

ASTM A335 Seamless Ferritic Alloy Steel Pipe For High Temperature P5/P9/P11/P12/P22/P91 Seamless Steel Pipe

ASTM A335 Pipe (ASME S/A335, Chorme-Moly) is a seamless ferritic Alloy-Steel Pipe for high temperature service. Pipe ordered to this specification shall be suitable for bending, flanging (vanstoning), and similar forming operations, and for fusion welding. Sometimes referred to as "P Grade”, chome moly pipe is popular in P-Grades P5, P9, P11, P22, and P91. The most common use of grades P11, P22, and P91 is in the power industry and petro-chemical plants, Grades P5 and P9 are commonly used in refineries.

Astm A335 Cs Seamless Pipe P5 / P9 / P11 / P12 / P22 / P91

Chemical Requirements of A335 Alloy Steel Seamless Pipes

Grade P-5 P-9 P-11 P-22 P-91 P-91 shall also include the following:
Element UNS Designation K41545 S50400 K11597 K21590 K91560
Carbon 0.15 max 0.15 max 0.05 - 0.15 0.05 - 0.15 0.08 - 0.12 V at 0.18 - 0.25
Manganese 0.30 - 0.60 0.30 - 0.60 0.30 - 0.60 0.30 - 0.60 0.30 - 0.60 N at 0.030 - 0.070
Phosphorous, max 0.025 0.025 0.025 0.025 0.020 Ni at 0.40 max
Sulfur, max 0.025 0.025 0.025 0.025 0.010 Al at 0.02 max
Silicon 0.50 max 0.25 - 1.00 0.50 - 1.00 0.50 max 0.20 -0.50 Cb at 0.06 - 0.10
Chromium 4.00 - 6.00 8.00 - 10.00 1.00 - 1.50 1.90 - 2.60 8.00 - 9.50 Ti at 0.01 max
Molybdenum 0.45 -0.65 0.90 - 1.10 0.44 - 0.65 0.87 - 1.13 0.85 - 1.05 Zr at 0.01 max

Tensile Requirements of A335 Alloy Steel Seamless Pipes

Seamless
P-5 P-9 P-11 P-22 P-91
Tensile Strength, min., psi
ksi 60 60 60 60 85
MPa 415 415 415 415 585
Yield Strength, min., psi
ksi 30 30 30 30 60
MPa 205 205 205 205 415
P91 shall not have a hardness not exceeding 250 HB/265 HV [25HRC].

Astm A335 Cs Seamless Pipe P5 / P9 / P11 / P12 / P22 / P91

FAQ
Q: Are you a factory or trading company ?
A: We're a factory founded in 2015, with covered area 40,000 suqare meters.

Q: How long is your delivery time?
A: depends on your quantity, in general around (30-45) days

Q: What is your payment term?
A: 30% T/T in advance, balance before shipping, L/C at sight

Q: How do you insure the quality?
A: We've a strict requirement on every process of manufacturing for the purpose of producing better products.
We supply the tube with MTC, 100% Eddy current test, 100% Ultrasonic test

Q: Do you supply samples ? Is it free or extra ??
A: Yes , We can provide free samples charge , but the freight cost should pay the client
